Partial Discharge Test Sets

Name: Partial Discharge Test Sets
Brand: NEO TELE-TRONIX PVT. LTD.
Price: 5000 MXN
Availability: InStock

Price 5000 MXN ($)/ Unit

Get a Price/Quote

MOQ : 1 Unit

Partial Discharge Test Sets Specification

Batteries Type
Not Required (Mains Operated)

Resistant Feature
Corrosion and Shock Resistant

Accuracy
1% of Reading

Usage & Applications
Checking Partial Discharge in Power Apparatus, Transformers, Cables, Insulation Materials, GIS, Motors

Pressure
Ambient (Non-pressurized operation)

Product Type
Manual , Automatic

Frequency (MHz)
50-60 Hertz (HZ)

Insulation Box
Available, High-grade Insulated Enclosure

Protection System
Integrated Overload and Short Circuit Protection

Size
Standard and Custom Sizes Available

Color
NA

Warranty
12 months

Display Type
Digital LCD with Backlight

Compliance Standards
IEC 60270, IS 6209

Software Interface
PC Connectivity via USB

Output Connector
Shielded BNC and Standard HV Terminal

Test Object Capacity
Up to 300 pF

Detection Sensitivity
Better than 5 pC

Noise Rejection
Advanced Filtering Provided

Power Supply
230V 10%, 50 Hz AC

Cooling Type
Natural Air-Cooled

Calibration
Factory Calibrated with Certificate

Partial Discharge Test Sets Trade Information

Minimum Order Quantity
1 Unit

FOB Port
kolkata

Supply Ability
50 Units Per Month

Delivery Time
7-15 Days

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
Wooden Package

Main Domestic Market
All India

Certifications
ISO 9001:2015

About Partial Discharge Test Sets

We are offering our valuable clients a wide range of Partial Discharge Test Sets that are widely used for instrument transformers for carrying out the partial discharge test. Our diligent professionals manufacture these test sets in compliance with international quality standards using high quality components. Our offered test sets are examined on different parameters to ensure their flawlessness at clients' end. We offer these Partial Discharge Test Sets in different specifications at economical rates.

Features of Partial Discharge Test Sets:

Accurate result
Robustness
Non-interrupted performance
Durability

Specification of Partial Discharge Test Sets:

Input : 230V (<=10 KVA), 415V (>10 KVA) , 50 / 60 Hz, 1.
AC Output : 0 to Max.
Rated O/P Voltage Capacity : 2KV to 500KV AC ( from several VA to hundreds of KVA ).
Duty : Intermittent ( 5min. ON,10min. OFF ).
Other at extra cost Type : Manual, Motor Operated, Fully Automatic.

FAQs of Partial Discharge Test Sets

Q: What are Partial Discharge Test Sets used for?

A: Partial Discharge Test Sets are used to detect, measure, and analyze partial discharge activity in electrical equipment, helping ensure insulation health, reliability, and safety in high-voltage systems.

Q: What types of models are available for this test set?

A: These test sets are available in both manual and automatic models, allowing users to choose based on operational preference and testing requirements.

Q: What is the operating frequency range of the test sets?

A: The equipment operates within a frequency range of 50-60 Hertz (Hz), making it suitable for standard industrial and electrical testing environments.

Q: Is there any warranty provided with the Partial Discharge Test Sets?

A: Yes, the test sets come with a 12-month warranty, covering manufacturing defects and ensuring reliable performance.

Q: What is your business nature and location for supplying these test sets?

A: We are a Manufacturer, Exporter, and Supplier of Partial Discharge Test Sets, based in Kolkata, West Bengal, India.

Enhanced Detection for Reliable Diagnostics

Our test sets stand out with exceptional detection sensitivity, better than 5 pC, ensuring even the smallest partial discharge events are detected. This enables precise assessment of electrical insulation quality, helping prevent future equipment failures. Advanced filtering drastically reduces noise interference, giving you accurate, trustworthy results every time.

User-Friendly Digital Interface & Secure Operation

Featuring a digital LCD display with backlight, the test sets offer clear, real-time data visualization. The shielded BNC and standard HV terminals ensure secure connections, while integrated overload and short-circuit protection safeguards both the user and equipment during operation. The natural air-cooled design guarantees effective cooling without additional maintenance.

Comprehensive Connectivity and Compliance

Easily connect the test set to your PC using the USB interface, allowing seamless data logging and analysis. Each unit is factory calibrated and provided with a calibration certificate, complying strictly with IEC 60270 and IS 6209 standards. This ensures industry-backed accuracy and peace of mind for all testing requirements.

FAQ's of Partial Discharge Test Sets:

Q: How is partial discharge detected with your test set?

A: The test set utilizes advanced sensors with a sensitivity superior to 5 pC, capturing even minimal discharge events. This, paired with robust noise filtering, enables accurate identification and analysis of partial discharges within insulation systems.

Q: What objects and applications is this test set suitable for?

A: It can test a wide range of power apparatus, including transformers, cables, GIS, motors, and insulation materials up to 300 pF. It's ideal for manufacturers, utilities, and service providers requiring reliable partial discharge assessments.

Q: When and where should the Partial Discharge Test Set be used?

A: Use the test set during commissioning, routine maintenance, or troubleshooting of electrical equipment, generally at substations, manufacturing units, or research labs. It operates under ambient pressure and does not require batteries, relying on a 230V AC mains supply.

Q: What is the process for operating and analyzing data with this test set?

A: Simply connect your test object to the shielded BNC or HV terminal, follow the digital LCD interface prompts, and monitor readings in real-time. For deeper analysis, connect the device to a PC via USB to log and evaluate data using compatible software.

Q: What are the benefits of the device's advanced noise rejection and protection features?

A: The sophisticated filtering system ensures highly accurate measurements by eliminating electrical noise. Integrated overload and short-circuit protections prolong equipment life and enhance user safety during high-voltage testing.

Q: Is the Partial Discharge Test Set compliant with international standards?

A: Yes, all units are factory calibrated, provided with certificates, and meet IEC 60270 and IS 6209 compliance requirements, making them suitable for export, manufacturing, and on-site applications in India and globally.
