NTT4DSA-5R DIGITAL TIME INTERVAL METER

Name: NTT4DSA-5R DIGITAL TIME INTERVAL METER
Brand: NEO TELE-TRONIX PVT. LTD.
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

NTT4DSA-5R DIGITAL TIME INTERVAL METER Specification

Pressure
Ambient (not pressure rated)

Accuracy
0.01 sec

Batteries Type
Not required (AC powered)

Usage & Applications
Measuring time intervals in various industrial and laboratory applications

Resistant Feature
Shock and moisture resistant

Product Type
Digital Time Interval Meter

Material
ABS High Grade Plastic

Measuring Voltage Range
220-240V AC

Operating Temperature
0C to 50C

Frequency (MHz)
50 Hz

Insulation Box
Yes

Protection System
Over voltage and short-circuit protection

Size
Standard panel mount size

Color
Black

Dimension (L*W*H)
269X204X132 Millimeter (mm)

Weight
4.2 Kilograms (kg)

Mounting Type
Panel Mount

Control buttons
Front panel operation

Time Range
0.01 sec to 9999 sec or as specified

IP Rating
IP20

Input Signal
Start & Stop (potential free contacts)

Reset Function
Manual/Auto

Humidity Range
Up to 90% RH non-condensing

Response Time
<50ms

Power supply
230V AC, 50Hz

Count Mode
Up/Down selectable

Relay Output
Changeover Relay Output

Display Type
7 Segment LED Digital Display

About NTT4DSA-5R DIGITAL TIME INTERVAL METER

NTPL" Digital Time Interval Meter is suitable designed and is made with extensive use of integrated circuit to achieve long and trouble free service

Technical Features

Display: Four digit display with 7 segment LED (12.5mm).

Range :

000.1mSec. to 999.9mSec.
0.001Sec. to 9.999Sec.
00.01Sec. to 99.99Sec.
000.1Sec. to 999.9Sec.
0001Sec. to 9999Sec.

Reset Facility : This is available in the form of push button switch.

Power Supply: 230 volts + 10% at 50 Hz AC.

Basic Accuracy: + 1%, + 1 digit.

Latching: This facility is available for only clean signals on contact closing and opening without bouncing.

Operation Mode: Opening or Closing of potential free contact.

Start or Stop: On contact opening / closing of the Relay under test.

Corresponding terminals are provided.

Approx. Dimension: L=269mmXW=204XH=132mm

Approx. Weight: 4.2Kg.

Documents:

Operation Manual, Works Test Report, Warrantee Certificate will be supplied along with the Set.

Precision Time Measurement

The NTT4DSA-5R Digital Time Interval Meter delivers high-accuracy time interval measurement with a resolution as fine as 0.01 seconds. Its wide range accommodates diverse industrial and laboratory timing needs, ensuring reliability in every application.

User-Friendly Panel Mount Design

Engineered for easy integration, this meter features a standard-sized panel mount configuration. The front panel buttons provide intuitive control, allowing seamless switching between manual and auto reset modes. Clear LED displays ensure real-time visibility of time intervals.

Durability and Compliance

Constructed from ABS high-grade plastic and equipped with an insulation box, the NTT4DSA-5R is resistant to shock and moisture. It features over voltage and short-circuit protection and operates efficiently within a wide humidity and temperature range, making it suitable for robust industrial use.

FAQ's of NTT4DSA-5R DIGITAL TIME INTERVAL METER:

Q: How does the NTT4DSA-5R Digital Time Interval Meter measure time intervals?

A: The meter measures time intervals by receiving start and stop signals through potential-free contacts. The duration between the two signals is precisely displayed on its 7-segment LED digital display, with a resolution as accurate as 0.01 seconds.

Q: What types of applications is this time interval meter suitable for?

A: It is ideal for measuring time intervals in industrial automation, laboratory timing experiments, and other environments where precise timing is critical. Its broad range and durable design support various operational needs.

Q: When should I use the manual versus the auto reset function?

A: Manual reset is useful when you need to control the reset point after each measurement, while auto reset is preferable for processes requiring continuous or immediate re-timing. Both options are accessible from the front panel, offering flexibility for different operations.

Q: Where is the NTT4DSA-5R typically installed?

A: Designed for panel mounting, this meter is commonly installed in control panels or measurement consoles in factories, testing labs, and industrial process environments.

Q: What is the process for selecting up or down counting mode?

A: You can easily select between up and down counting modes using the front panel controls. This flexibility allows you to measure elapsed or remaining time based on your specific application.

Q: Does the meter require batteries for operation?

A: No, the NTT4DSA-5R operates directly from a 230V AC, 50Hz power supply and does not require any batteries, making maintenance simple and cost-effective.

Q: What are the key benefits of using this time interval meter?

A: Key benefits include high measurement accuracy, robust build quality for challenging environments, shock and moisture resistance, fast response time, and comprehensive protection features, ensuring long-term dependable performance.
